Ink | |
Number of Nozzles | Total 1,792 nozzles |
Ink Bottles (Type / Colours) | GI-71 (Pigment / Black), (Dye-Based Ink / Cyan, Magenta, Yellow) |
Maintenance Cartridge | MC-G02 |
Maximum Printing Resolution | 4,800 (horizontal)*1 x 1,200 (vertical) dpi |
Print Speed*2(Approx.)
Based on ISO/IEC 24734 |
|
Document (ESAT/Simplex) | 9.1 / 5 ipm (mono/colour) |
Document (FPOT Ready/Simplex) | 9 / 16 sec (mono/colour) |
Photo (4 x 6″) (PP-201/Borderless) | 45 sec |
Printable Width | Up to 203.2 mm (8″) Borderless: Up to 216 mm (8.5″) |
Printable Area | |
Borderless Printing*3 | Top/Bottom/Left/Right margin: each 0 mm |
Bordered Printing | Envelope (COM10/DL): Top margin: 8 mm, Bottom margin: 12.7 mm, Left/Right margin: 3.4 mmEnvelopes (C5/Monarch): Top margin: 8 mm, Bottom margin: 12.7 mm, Left/Right margin: 5.6 mmSquare 5 x 5″ (127 x 127 mm): Top/Bottom/Left/Right margin: 6 mmSquare 3.5 x 3.5″ (89 x 89 mm): Top/Bottom/Left/Right margin: 5 mmLTR/LGL/Foolscap/B-Oficio: Top margin: 3 mm, Bottom margin: 5mm, Left margin: 6.4 mm, Right margin 6.3 mm M-Oficio: Others: |
Support Media | |
Rear Tray | Plain Paper (64-105 g/m²) Photo Paper Pro Luster (LU-101) Photo Paper Plus Glossy II (PP-201/PP-208) Matte Photo Paper (MP-101) Double Sided Matte Paper (MP-101D) Glossy Photo Paper “Everyday Use” (GP-508) High Resolution Paper (HR-101N) Photo Paper Plus Semi-Gloss (SG-201) Photo Stickers (PS-208/PS-808) Envelope |
Paper Size | |
Rear Tray | A4, A5, A6, B5, LTR, LGL, Executive (184.2 x 266.7 mm), Legal (India) (215 x 345 mm), Foolscap (215.9 x 330.2 mm), F4 (215.9 x 330.2 mm), Oficio2 (215.9 x 330.2 mm), B-Oficio (216 x 355 mm), M-Oficio (216 x 341 mm), 4 x 6″, 5 x 7″, 7 x 10″, 8 x 10″, Envelopes DL, Envelopes COM10, Envelopes C5, Envelopes Monarch (98.4 x 190.5 mm), Square (3.5 x 3.5”, 5 x 5”), Card Size (91 x 55 mm)
Custom size: |
Paper Size (Borderless)*4 | A4, LTR, 4×6″, 5×7″, 7×10″, 8×10″ Square (3.5 x 3.5″, 5 x 5″), Card Size (91 x 55 mm) |
Paper Handling (Maximum Number) | |
Rear Tray | Plain Paper (A4, 64 g/m²) = 100 High Resolution Paper (HR-101N) = 80 Photo Paper Plus Glossy II (PP-201, 4 x 6″) = 20 Photo Paper Plus Semi-Gloss (SG-201, 4 x 6″) = 20 Glossy Photo Paper “Everyday Use” (GP-508, 4 x 6″)=20 Matte Photo Paper (MP-101, 4 x 6″) = 20 |
Paper Weight | |
Rear Tray | Plain Paper: 64-105 g/m² Canon paper: Max paper weight: approx. 275 g/m² (Photo Paper Plus Glossy II, PP-201) |
Ink End Sensor | Dot count type |
Print Head Alignment | Manual |
Scan*5
Scanner Type | Flatbed |
Scanner Method | CIS (Contact Image Sensor) |
Optical Resolution*6 | 600 x 1,200 dpi |
Scanning Bit Depth (Input/Output) | |
Grayscale | 16 bit/8 bit |
Colour | RGB each 16 bit/8 bit |
Line Scanning Speed*7 | |
Grayscale | 1.5 ms/line (300 dpi) |
Colour | 3.5 ms/line (300 dpi) |
Maximum Document Size | |
Flatbed | A4/LTR |
Copy
Maximum Document Size | A4/LTR |
Compatible Media | |
Size | A4, A5, A6, B5, LTR, LGL, Executive (184.2 x 266.7 mm), Legal (215 x 345 mm), Foolscap (215.9 x 330.2 mm), B-Oficio (216 x 355 mm), M-Oficio (216 x 341 mm), 4 x 6″, 5 x 7″, Square (5 x 5″), Card Size (91 x 55 mm) |
Type | Plain Paper Photo Paper Plus Glossy II (PP-201, PP-208) Photo Paper Pro Luster (LU-101) Photo Paper Plus Semi-Gloss (SG-201) Matte Photo Paper(MP-101) Glossy Photo Paper(GP-508) |
Image Quality | 3 positions (Economy, Standard, High) |
Density Adjustment | 9 positions, Auto intensity (AE copy) |
Copy Speed*8(Approx.)
Based on ISO/IEC 24734 |
|
Document (Colour): (sFCOT/Simplex) / (sESAT/Simplex) | 28 sec / 2.6 ipm |
Multiple Copy | |
Mono/Colour | Max. 99 pages |
Network
Protocol | SNMP, HTTP, TCP/IP (IPv4/IPv6) |
Wireless LAN | |
Network Type | IEEE802.11b/g/n |
2.4GHz Channel (1 – 11) | US/HK/TW/LTN/BR/CAN |
2.4GHz Channel (1 – 13) | JP/KR/EUR/AU/ASA/CN/EMBU |
Security | WEP 64/128 bit WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES) |
Direct Connection (Wireless LAN) | Available |
Printing Solutions
AirPrint | Available |
Mopria | Available |
Canon Print Service (for Android) |
Available |
PIXMA Cloud Link From smartphone or tablet |
Available |
Easy Photo-Print Editor (for iOS/Android) |
Available |
Canon PRINT Inkjet/SELPHY (for iOS/Android) |
Available |
Camera Direct | Wireless LAN |
System Requirements*9
Windows 10 / 8.1 / 7 SP1 (operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)macOS 10.12.6 ~ 10.15Chrome OS |
General Specifications
Operation Panel | |
Display | 2-Line LCD |
Language | 32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese |
Interface | USB 2.0 |
PictBridge (Wireless) | Available |
Operating Environment*10 | |
Temperature | 5 – 35°C |
Humidity | 10 – 90% RH (no dew condensation) |
Recommended Environment*11 | |
Temperature | 15 – 30°C |
Humidity | 10 – 80% RH (no dew condensation) |
Storage Environment | |
Temperature | 0 – 40°C |
Humidity | 5 – 95% RH (no dew condensation) |
Quiet Mode | Available |
Acoustic Noise (PC Print) (Approx.) | |
Plain Paper (A4, B/W)*12 | 49.5 dB(A) |
Power | AC 100-240 V, 50/60 Hz |
Power Consumption (Approx.) | |
OFF | 0.2 W |
Standby (scanning lamp is off) USB connection to PC |
0.6 W |
Copying*13 USB connection to PC |
16 W |
Duty Cycle | Up to 3,000 pages/month |
Dimensions (WxDxH) (Approx.) | |
Factory Configuration | 445 x 330 x 167 mm |
Output/ADF Trays Extended | 445 x 555 x 238 mm |
Weight (Approx.) | 6.4 kg |
Page Yield
Plain Paper (A4 pages) (ISO/IEC 24712 test file)*14 |
Standard: GI-71 PGBK: 6,000 GI-71 C, M, Y: 7,700*15GI-71S PGBK: 3,100 GI-71S C, M, Y: 4,400*15Economy*16: GI-71 PGBK: 7,600 GI-71 C, M, Y: 8,100*15GI-71S PGBK: 3,900 GI-71S C, M, Y: 4,600*15 |
Photo Paper (PP-201, 4 x 6″) (ISO/IEC 29103 test file)*14 |
Standard: GI-71 PGBK: NA*17 GI-71 C, M, Y: 2,200GI-71S PGBK: NA*17 GI-71S C, M, Y: 1,200 |
- Ink droplets can be placed with a pitch of 1/4,800 inch at minimum.
- Document print speeds are the average of ESAT (Word, Excel, PDF) in Office Category Test for the default simplex mode, ISO/IEC 24734.
Photo print speed is based on the default setting using ISO/JIS-SCID N2 on Photo Paper.
Plus Glossy II and does not take into account data processing time on host computer.
Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used, etc. - Paper types NOT supported for borderless printing are as follows: Envelope, High Resolution Paper, T-Shirt Transfer, Photo Stickers.
- The following media does NOT support borderless printing: High Resolution Paper, T-Shirt Transfer, Photo Stickers.
- TWAIN driver (ScanGear) is based on the TWAIN specification V1.9 and requires the Data Source Manager comes with the operating system.
- Optical resolution scan is available, only when you use TWAIN Driver.
Optical resolution is a measure of maximum hardware sampling resolution, based on ISO 14473 standard. - The fastest speed in Hi-Speed USB on Windows PC. Transfer time to computer is not included.
- Copy speeds are the average of sFCOT and sESAT, ISO/IEC 29183.
Copy speeds (ADF) are ESAT of copy in sequence, ISO/IEC 24735.
Copy speed may vary depending on document complexity, copy mode, page coverage, type of paper used, etc. and does not take into account warm-up time. - Please visit https://asia.canon to check OS compatibility and to download the latest driver updates.
- The performance of the printer may be reduced under certain temperature and humidity conditions.
- For the temperature and humidity conditions of papers such as photo paper, refer to the paper’s packaging or the supplied instructions.
- Acoustic Noise is measured based on ISO7779 standard with default setting.
- Copy: When copying ISO/JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings.
- Declared yield value in accordance with ISO/IEC 24711 (for A4 size) using ISO/IEC 24712 test file, and ISO/IEC 29102 (for 4×6″ size) using ISO/IEC 29103 test file. Values obtained by continuous printing.
- Based on 1 set of colour bottles.
- Published highest yield is achievable based on Standard ink bottle and printing on Economy mode. The Economy mode reduces the ink consumption by lowering the density. More pages can be printed by using this mode.
- Black ink is not used when printing under this condition. However, a minimal amount of black ink is used for maintenance purpose.
